3385 | Mennekes
CEE surface-mounted socket, 5 pole, 16 A/400 V, gray/red, 6 h, IP44, 3385
Order No.: 12N190
EAN: 4015394206156
MPN:
3385
Unit Price (€ / pc.)
108.4804 € *
Available: 3 pcs.
Leadtime: 3 Weeks **
Total Price:
108.48 € *
Price list
Quantity
Price per unit*
1 pcs.
108.4804 €
3 pcs.
105.2436 €
10 pcs.
101.6260 €
25 pcs.
98.9009 €
100 pcs.
94.5693 €
*incl. VAT plus shipping costs
**Subject to prior sale
With TwinCONTACT, type 33.
Splashproof to IP 44, straight insertion, with mounting flange and hinged lid. Version: to DIN VDE 0623, EN 60309-2. Color: electrical-gray and/or color code. Housing and insert: made of high strength plastic (AMAPLAST). Contacts (number of poles/contact type): 3-pole/2 P + E, 5-pole/3 P + N + E. Termination: screw terminals. Table index: type, number of poles, rated current, operating voltage (50/60 Hz), color code.
Screwless spring clamp technology. Suitable for race wiring.
Type: 3385, 5 - pole, 16 A, 400 V, red
Technical specifications
| Colour | gray/red | |
| Frequency range | 50 to 60 Hz | |
| Degree of protection (IP) | IP44 | |
| Cable cross-section | 1.5-4.0 mm² | |
| Pin number | 5 pole | |
| Version | surface-mounted socket | |
| Nominal power | 16 A/400 V | |
| Connection | spring-clamp connection |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
