5ETH965 | MEC Switches

Short-stroke pushbutton, 1 Form A (N/O), 50 mA/24 VDC, unlit , actuator (black), 6.5 N, THT, 5ETH965

Order No.: 12G2070
EAN: 4099889205398
MPN:
5ETH965
Series: Multimec 5E
5ETH965 MEC Switches Tactile Switches Image 1
5ETH965 MEC Switches Tactile Switches Image 2
Image may differ
Unit Price (€ / pc.)
1.9992 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
2.00 € *
Price list
Quantity
Price per unit*
1 pcs.
1.9992 €
25 pcs.
1.6898 €
100 pcs.
1.5708 €
250 pcs.
1.4875 €
1000 pcs.
1.3566 €
*incl. VAT plus shipping costs
Subject to prior sale

Tactile switch, 5ETH965, MEC

Multimec 5E high performance tactile switch, robust, sealed to IP67.

Features

  • Anti-rotation thanks to snap-on cap retetion system
  • Robust
  • Sealed to IP67
Technical specifications
Filter Property Value
actuating force 6.5 N
Height 12.5 mm
Actuator colour black
Width 15 mm
Latching switching function 1 Form A (N/O)
Connection THT
illuminated No
Breaking capacity 50 mA/24 VDC
Contact material silver-plated
Length 15 mm
Logistics
Property Value
Country of origin DK
Customs tariff number 85365080
Compliance
Property Value
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
