MDR-40-12 | MEAN WELL
Power supply, 12 to 15 VDC, 3.33 A, 40 W, MDR-40-12
Unit Price (€ / pc.)
30.6901 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
30.69 € *
Price list
Quantity
Price per unit*
1 pcs.
30.6901 €
5 pcs.
28.8456 €
50 pcs.
25.5255 €
*incl. VAT plus shipping costs
Subject to prior sale
Power supply, MDR-40-12, MEAN WELL
AC-DC Industrial DIN rail power supply, output 12 VDC at 3.33 A, plastic housing.
Features
- Universal AC input/full range
- Protection functions: Short circuit, overload, overvoltage
- Cooling by free air convection
- LED indicator for power on
- DC OK relay contact
- Power consumption in idle mode < 0.3 W
- 100 % full load burn-in test
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 3.33 A | |
| Output voltage DC | 12 to 15 VDC | |
| Input voltage AC | 85-264 VAC, 120-370 VDC | |
| Power | 40 W | |
| efficiency | 86 % | |
| Width | 40 mm | |
| Height | 90 mm | |
| Depth | 100 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85043180 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
