MDR-100-48 | MEAN WELL
Power supply, 48 to 56 VDC, 2 A, 100 W, MDR-100-48
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
56.1442 € *
Standard delivery time from the manufacturer is: On Request
Power supply, MDR-100-48, MEAN WELL
AC-DC industrial DIN rail power supply; output 48 VDC at 2 A; plastic housing.
Features
- Universal AC input/full range
- Protection functions: Short circuit, overload, overvoltage, overtemperature
- ZCS/ZVS technology to reduce power dissipation
- Cooling by free air convection
- DC OK relay contact
- Power consumption without load <1 W
- LED indicator for power on
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 2 A | |
| Output voltage DC | 48 to 56 VDC | |
| Input voltage AC | 85-264 VAC, 120-370 VDC | |
| Power | 100 W | |
| efficiency | 87 % | |
| Width | 55 mm | |
| Height | 90 mm | |
| Depth | 100 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85043180 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
