2650 12 T12CB T | Lutronic

Plug, 12 pole, solder cup, quick locking, straight, 2650 12 T12CB T

Order No.: 72F3020
EAN: 4099889742107
MPN:
2650 12 T12CB T
Series: Quicklock
2650 12 T12CB T Lutronic Other Circular Connectors
Image may differ
Unit Price (€ / pc.)
10.9480 € *
Available: 25 pcs.
Total Price:
10.95 € *
Price list
Quantity
Price per unit*
1 pcs.
10.9480 €
10 pcs.
9.6390 €
50 pcs.
8.9726 €
150 pcs.
8.5799 €
500 pcs.
8.1515 €
*incl. VAT plus shipping costs
Subject to prior sale

Quicklock circular connector, IP67

Quicklock plug, IP67, size 20, straight version, with plastic housing and solder terminals

Features

  • Temperature range: -40 °C/+80 °C
  • Rated voltage: 500 V
  • Contact resistance: ≤ 5 mΩ
  • Cable diameter: 7.0-13.0 mm
  • Approvals: cULus
Technical specifications
Version plug
Cable cross-section 0.34-0.75 mm²
Pin number 12 pole
Orientation straight
Contact connection solder cup
Type of locking quick locking
Cable diameter 7 to 13 mm
Assembly cable assembly
Additional parts equipped
contact surface gold-plated
Shell Material PBT
Logistics
Country of origin CN
Customs tariff number 85366990
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
