2650 02 T12CB T | Lutronic

Plug, 2 pole, solder cup, quick locking, straight, 2650 02 T12CB T

Order No.: 72F3014
EAN: 4099889742046
MPN:
2650 02 T12CB T
Series: Quicklock
2650 02 T12CB T Lutronic Other Circular Connectors
Image may differ
Unit Price (€ / pc.)
10.1745 € *
Available: 12 pcs.
Total Price:
10.17 € *
Price list
Quantity
Price per unit*
1 pcs.
10.1745 €
10 pcs.
8.9607 €
50 pcs.
8.3538 €
150 pcs.
7.9849 €
500 pcs.
7.5684 €
*incl. VAT plus shipping costs
Subject to prior sale

Quicklock circular connector, 0252 02, Lumberg

Quicklock plug with locking latch, IP67, size 20, straight version, with plastic housing and solder terminals

Technical Data

  • Contact connection: Solder cup
  • Rated voltage: 500 V
  • Number of positions: 2
  • Cable cross-section: 2.5-4.0 mm²
  • Shell material: PBT
Technical specifications
Version plug
Cable cross-section 2.5-4.0 mm²
Pin number 2 pole
Orientation straight
Contact connection solder cup
Type of locking quick locking
Cable diameter 7 to 13 mm
Assembly cable assembly
Additional parts equipped
contact surface gold-plated
Shell Material PBT
Logistics
Country of origin CN
Customs tariff number 85366990
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
