2640 09 T12CB A | Lutronic
Jack, 9 pole, solder cup, quick locking, straight, 2640 09 T12CB A
Unit Price (€ / pc.)
7.3423 € *
Standard delivery time from the manufacturer is: 20 Weeks
Quicklock circular connector, 0262 09, Lumberg
Quicklock socket, IP67, size 20, straight version, with plastic housing and solder terminals
Technical Data
- Contact connection: Solder cup
- Rated voltage: 500 V
- Number of positions: 9
- Cable cross-section: 0.34-0.75 mm²
- Shell material: PBT
Technical specifications
| Version | jack | |
| Cable cross-section | 0.34-0.75 mm² | |
| Pin number | 9 pole | |
| Orientation | straight | |
| Contact connection | solder cup | |
| Type of locking | quick locking | |
| Cable diameter | 7 to 13 mm | |
| Assembly | cable assembly | |
| Additional parts | equipped | |
| contact surface | gold-plated | |
| Shell Material | PBT |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85366990 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
