SGR 30 | Lumberg

Panel plug, 3 pole, THT, screw locking, straight, SGR 30

Order No.: 70F9630
EAN: 4099889740998
MPN:
SGR 30
Series: SGR
SGR 30 Lumberg Other Circular Connectors
Image may differ
Unit Price (€ / pc.)
4.5696 € *
Available: 72 pcs.
Total Price:
4.57 € *
Price list
Quantity
Price per unit*
1 pcs.
4.5696 €
10 pcs.
4.0341 €
100 pcs.
3.5224 €
200 pcs.
3.3915 €
*incl. VAT plus shipping costs
Subject to prior sale

Chassis plug, SGR 30, LUMBERG

Chassis plug IP40 with threaded joint M16, for printed circuit boards and back side mounting.

Technical specifications
Filter Property Value
Shell Material metal
Additional parts equipped
contact surface gold-plated/silver-plated
Contact connection THT
Version DIN panel plug
Orientation straight
Cable diameter 25.4 mm
Assembly rear mounting
Type of locking screw locking
Pin number 3 pole
Logistics
Property Value
Country of origin CZ
Customs tariff number 85366990
Original Packaging Carton with 50 pieces
Compliance
Property Value
SVHC free Yes
RoHS conform Yes
Date of RoHS guidelines 3/31/15
