KGV 80 | Lumberg
Panel socket, 8 pole, solder cup, screw locking, straight, KGV 80
Unit Price (€ / pc.)
6.1642 € *
Next delivery: 135 pcs. on 2025-11-21
Total Price:
6.16 € *
Price list
Quantity
Price per unit*
1 pcs.
6.1642 €
10 pcs.
5.4264 €
100 pcs.
4.7481 €
200 pcs.
4.5696 €
*incl. VAT plus shipping costs
Subject to prior sale
Chassis socket, KGV 80, LUMBERG
Chassis socket IP40, with threaded joint M16 and solder terminals for back side mounting.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Contact connection | solder cup | |
| contact surface | gold-plated/silver-plated | |
| Assembly | rear mounting | |
| Shell Material | metal | |
| Additional parts | equipped | |
| Orientation | straight | |
| Pin number | 8 pole | |
| Version | DIN panel socket | |
| Type of locking | screw locking | |
| Cable cross-section | 0.75 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Original Packaging | Carton with 50 pieces |
| Country of origin | CZ |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
