0331 14 | Lumberg
Plug, 14 pole, solder cup, screw locking, straight, 0331 14
Unit Price (€ / pc.)
14.0420 € *
Standard delivery time from the manufacturer is: 9 Weeks
Plug, 0331 14, LUMBERG
Plug IP68, with threaded joint M16 and solder terminals.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Contact connection | solder cup | |
| contact surface | nickel-plated/gold-plated | |
| Shell Material | copper alloy | |
| Orientation | straight | |
| Assembly | cable assembly | |
| Type of locking | screw locking | |
| Pin number | 14 pole | |
| Version | plug | |
| Cable diameter | 4 to 8 mm | |
| Cable cross-section | 0.75 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | PL |
| Original Packaging | Carton with 50 pieces |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
