0131 03 | Lumberg

Plug, 3 pole, solder cup, bayonet locking, straight, 0131 03

Order No.: 70F640
EAN: 4099889739282
MPN:
0131 03
Series: 0131
0131 03 Lumberg Other Circular Connectors Image 1
0131 03 Lumberg Other Circular Connectors Image 2
Image may differ
Unit Price (€ / pc.)
5.4264 € *
Available: 20 pcs.
Total Price:
5.43 € *
Price list
Quantity
Price per unit*
1 pcs.
5.4264 €
10 pcs.
4.9861 €
50 pcs.
4.5339 €
100 pcs.
4.0817 €
*incl. VAT plus shipping costs
Subject to prior sale

DIN plug, 0131 03, LUMBERG

DIN plug, straight version, shielded, with metal housing, bend protection and solder terminals.

Technical specifications
Version DIN plug
Cable cross-section 0.75 mm²
Pin number 3 pole
Orientation straight
Contact connection solder cup
Type of locking bayonet locking
Cable diameter 7 mm
Assembly cable assembly
Additional parts equipped
contact surface silver-plated
Shell Material metal
Logistics
Country of origin TW
Customs tariff number 85366990
Original Packaging Carton with 50 pieces
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
