52180 | Lumberg Automation
Panel socket, M12, 5 pole, crimp connection, screw locking, straight, 52180
Unit Price (€ / pc.)
   9.0797 €  *
   Standard delivery time from the manufacturer is: 22 Weeks
 Sensor-actuator connector, 52180, Lumberg Automation
M12 Data receptacle connector: female, front mount, M12 - mating side, stranded wires - connecting side, 5-pin, unshielded, metallic grey housing, 50 V AC/60 V DC, 4 A.
Features
- Contact material: CuNi
- Pollution degree: 3
- Overvoltage category: III
 Technical specifications

 | Filter | Property | Value |
|---|---|---|
| Contact connection | crimp connection | |
| contact surface | gold-plated | |
| Assembly | front mounting | |
| Coding | B | |
| Thread size | M12 | |
| Orientation | straight | |
| Degree of protection (IP) | IP65/IP67 | |
| Product type | panel socket | |
| Pin number | 5 pole | |
| Type of locking | screw locking |
 Download
  Logistics

 | Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | CZ |
 Compliance

 | Property | Value |
|---|---|
| Substance description | Octamethylcyclotetrasiloxane, decamethylcyclopentasiloxane, dodecamethylcyclohexasiloxane, Lead |
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
