19354 | Lumberg Automation
Socket, 1/2, 3 pole, crimp connection, screw locking, straight, 19354
Unit Price (€ / pc.)
7.4018 € *
Available: 0 pcs.
Leadtime: 15 Weeks **
Sensor-actuator connector, 19354, Lumberg Automation
1/2"-20UNF-2B Sensor/actuator receptacle connector: female, front mount, 1/2"-20UNF-2B - mating side, stranded wires - connecting side, 3-pin, U (1/2"-20UNF-2B)-coded, unshielded, metallic grey housing, 230 V AC/DC, 4 A.
Features
- Contact material: CuZn
- Housing material: CuZn, nickel-plated
- Pollution degree: 3
- Degree of protection: IP67
Technical specifications
| Version | socket | |
| Thread size | 1/2 | |
| Coding | U | |
| Contact connection | crimp connection | |
| contact surface | gold-plated | |
| Assembly | front mounting | |
| Orientation | straight | |
| Pin number | 3 pole | |
| Degree of protection (IP) | IP65/IP67 | |
| Type of locking | screw locking |
Download
Logistics
| Country of origin | CZ |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
