11671 | Lumberg Automation
Plug, M8, 4 pole, solder connection, snap-in/screw locking, straight, 11671
Unit Price (€ / pc.)
2.5109 € *
Standard delivery time from the manufacturer is: 4 Weeks
Sensor-actuator connector, 11671, Lumberg Automation
M8 Insert Sensor/actuator receptacle connector: male, insert, M8 - mating side, solder contacts - connecting side, 4-pin, unshielded, metallic grey housing, 30 V AC/DC, 4 A (24 AWG).
Features
- Contact material: CuZn
- Pollution degree: 3
- Overvoltage category: II
Technical specifications
| Pin number | 4 pole | |
| Type of locking | snap-in/screw locking | |
| Contact connection | solder connection | |
| Product type | plug | |
| Coding | A | |
| Orientation | straight | |
| Degree of protection (IP) | IP67/IP69K | |
| Thread size | M8 | |
| contact surface | gold-plated |
Download
Logistics
| Customs tariff number | 85366990 |
| Country of origin | CZ |
Compliance
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
