91740 | Lumberg Automation

Sensor actuator cable, M8-cable plug, straight to open end, 8 pole, 0.5 m, orange, 1.5 A, 91740

Order No.: 72F1702
EAN: 4099891165383
MPN:
91740
RSMF 8/0,5M
Series: RSMF
91740 Lumberg Automation Sensor-Actuator Cables
Image may differ
Unit Price (€ / pc.)
12.6973 € *
Standard delivery time from the manufacturer is: 22 Weeks
Total Price:
126.97 € *
*incl. VAT plus shipping costs
Subject to prior sale
10 pcs.
12.6973 €

Receptacle connectors with screw connection, type RSMF 8/0,5M.

For front mounting, dressed with hookup stranded wire, 8-pole, with screw lock; Rated voltage/current: 32 V/1,0 A. Test voltage (60 s): 800 VRMS. Insulation resistance: min. 10 Gohm. Degree of soiling: 3. Degree of protection: IP 67 in screwed state. Housing material: CuZn, nickel-plated. Contact block: PA. Contacts: copper zinc, 0,8 µm gold-plated on nickel substrate. Ambient temperatures: - 25 to +80 °C.

Technical specifications
Filter Property Value
Cable length 0.5 m
Colour orange
max. Voltage 60 V
Degree of protection (IP) IP67
Rated current 1.5 A
Connection (2) open end
Pin number 8 pole
Connection (1) M8-cable plug, straight
Logistics
Property Value
Country of origin CZ
Customs tariff number 85366990
Compliance
Property Value
Date of RoHS guidelines 3/31/15
Substance description Octamethylcyclotetrasiloxane, decamethylcyclopentasiloxane, dodecamethylcyclohexasiloxane, Lead
SVHC free No
RoHS conform Yes
