8955 | Lumberg Automation
Sensor actuator cable, M12-cable plug, straight to M12-cable plug, straight, 8 pole, 25 m, X-FRNC/LSNH, blue, 0.5 A, 8955
Unit Price (€ / pc.)
285.60 € *
Available: 0 pcs.
Leadtime: 16 Weeks **
Double-ended cordset, BRSTS 8X-BRSTS 8X-552/25 M, Lumberg Automation
Gigabit Ethernet Cat7 Data double-ended cordset: Male straight X-coded black M12 Railway to male straight X-coded black M12 Railway, shielded, 50 V AC / 60 V DC, 0.5 A; X-FRNC/LSNH blue cable, 8-wires, 4x2x0.25 mm².
Technical specifications
| Connection (1) | M12-cable plug, straight | |
| Connection (2) | M12-cable plug, straight | |
| Colour | blue | |
| Cable length | 25 m | |
| LED display | No | |
| Material | X-FRNC/LSNH | |
| max. Voltage | 60 V | |
| Rated current | 0.5 A | |
| Pin number | 8 pole | |
| Degree of protection (IP) | IP67 |
Download
Logistics
| Country of origin | CZ |
| Customs tariff number | 85444290 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
