62521 | Lumberg Automation
Sensor actuator cable, M12-cable plug, straight to M12-cable socket, straight, 5 pole, 5 m, PUR, black, 4 A, 62521
Unit Price (€ / pc.)
40.7218 € *
Standard delivery time from the manufacturer is: 5 Weeks
Double-ended cordset, 0935 365 103/5 M, Lumberg Automation
CANopen/DeviceNet Data double-ended cordset: Male straight A-coded black M12 Standard to female straight A-coded black M12 Standard, 50 V AC / 60 V DC, 4 A; PUR violet cable, 4-wires, Data: 2x0.25 mm² + Power: 2x0.34 mm²
Technical specifications
| Cable length | 5 m | |
| Colour | black | |
| Degree of protection (IP) | IP67 | |
| Rated current | 4 A | |
| Connection (2) | M12-cable socket, straight | |
| Pin number | 5 pole | |
| Material | PUR | |
| Connection (1) | M12-cable plug, straight |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85444290 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Octamethylcyclotetrasiloxane, decamethylcyclopentasiloxane, dodecamethylcyclohexasiloxane, Lead |
| SVHC free | No |
| RoHS conform | Yes |
