02511.25MXL | Littelfuse
Micro fuse 2.8 x 7.11 mm, 1.25 A, FF, 125 V (DC), 125 V (AC), 50 A breaking capacity, 02511.25MXL
Unit Price (€ / pc.)
0.7497 € *
Standard delivery time from the manufacturer is: 8 Weeks
Slo-Blo Fuse, 02511.25MXL, Littelfuse
The 02511.25MXL is a 5×20 mm Slo-Blo glass body cartridge fuse designed to UL specification. It is used as supplementary protection in appliance or utilization equipment to provide individual protection for components or internal circuits.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Tripping characteristics | FF | |
| Design | 2.8 x 7.11 mm | |
| Breaking capacity | 50 A | |
| Version | micro fuse | |
| Rated voltage (AC) | 125 V | |
| Rated current | 1.25 A | |
| Length | 7.11 mm | |
| diameter | 2.8 mm | |
| Enclosure | ceramic tube | |
| Rated voltage (DC) | 125 V |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | PH |
| Customs tariff number | 85361010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
