LT1510CS8#PBF | Linear Technology
Battery charger IC, SOIC-8, LT1510CS8#PBF
Order No.: 41S6772
EAN: 4099879097446
MPN:
LT1510CS8#PBF
Unit Price (€ / pc.)
11.4954 € *
Standard delivery time from the manufacturer is: 2 Weeks
Battery Charging IC, LT1510CS8#PBF, Linear Technology
The LT1510CS8#PBF current mode PWM battery charger is the smallest, simplest, most efficient solution to fast-charge modern rechargeable batteries including lithium-ion (Li-Ion), nickel-metal-hydride (NiMH) and nickel-cadmium (NiCd) that require constant-current and/or constant-voltage charging. The internal switch is capable of delivering 1.5A DC current (2A peak current). The 0.1Ω onboard current sense resistor makes the charging current programming very simple. One resistor (or a programming current from a DAC) is required to set the full charging current (1.5A) to within 5% accuracy. The LT1510CS8#PBF with 0.5% reference voltage accuracy meets the critical constant-voltage charging requirement for lithium cells.
Features
- High Efficiency Current Mode PWM with 1.5A Internal Switch and Sense Resistor
- Current Sensing Can Be at Either Terminal of the Battery
- Charging Current Soft Start
- Shutdown Control
Applications
- Chargers for NiCd, NiMH and Lithium Batteries
- Step-Down Switching Regulator with Precision Adjustable Current Limit
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of pins | 8 | |
| Enclosure | SOIC-8 | |
| Input voltage | 7.8 V | |
| max. operating temperature | 70 °C | |
| min. operating temperature | 0 °C | |
| Assembly | SMD |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Bar with 100 pieces |
| Country of origin | US |
| Customs tariff number | 85423390 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
