61803930 | LAPP
Protective hose, inside Ø 91.3 mm, outside Ø 106 mm, BR 170 mm, PA, gray, 61803930
Order No.: 33P3870
EAN: 4044777577774
MPN:
61803930
FIPLOCK FPAF 95/91,3X106,0 GY 10M
Series: FIPLOCK PA6
Unit Price (€ / mtr.)
73.4944 € *
Standard delivery time from the manufacturer is: 6 Weeks
Protective sleeve, 61803930, LAPP
The 61803930 is made from highly flame retarded specially modified Polyamide 6. It is suitable for cable protection applications where low fire hazard is mandatory. The excellent self-extinguishing and low smoke generation characteristics are main criterions for the selection of these products. With it`s good complementary mechanical performances this conduit suits technically high demanding applications such like rolling stock and public transport equipment in general.
Features
- Good chemical resistance
- Flame-retardant
- Halogen-free
- Cold-resistant
- Assembly time
- Low weight
- Oil-resistant
- UV-resistant
- Waterproof
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | gray | |
| min. operating temperature | -45 °C | |
| max. operating temperature | 120 °C | |
| Outer diameter | 106 mm | |
| Material | PA | |
| Flame-retardant | Yes | |
| Inner diameter | 91.3 mm | |
| Bending radius | 170 mm | |
| Nominal width | 95 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 39173200 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
