15500263/50 | LAPP
PVC earth cable NYY-J 5 G 4.0 mm², unshielded, 15500263/50
Unit Price (€ / mtr.)
5.3193 € *
Available: 0 mtr.
Leadtime: On Request **
Total Price:
5.32 € *
Price list
Quantity
Price per unit*
1 mtr.
5.3193 €
10 mtr.
4.8314 €
50 mtr.
4.3554 €
100 mtr.
3.9746 €
500 mtr.
3.6176 €
*incl. VAT plus shipping costs
**Subject to prior sale
Technical specifications
| Core insulation material | PVC | |
| Core colour sequence | VDE 0293-308 | |
| Number of cores | 5 | |
| Version | Erdleitung | |
| Outer diameter | 17 mm | |
| Halogen free | No | |
| Cable material | Kupfer, blank | |
| Cable cross-section | 4,0 mm² | |
| Material | PVC | |
| Rated voltage | 1 kV | |
| Rated voltage U0 | 600 V | |
| Test voltage | 4 kV | |
| Shielding | ungeschirmt | |
| Protective conductor available | Yes | |
| Temperature range (active) | -5 °C bis 50 °C | |
| Temperature range (unmoved) | -40 °C bis 70 °C |
Download
Logistics
| Country of origin | PL |
| Customs tariff number | 85444999 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
