4726032 | LAPP

Polymer-Stranded wire, high flexible, halogen free, H07Z-K, 2.5 mm², AWG 14, brown, outer Ø 4.3 mm, 4726032

Order No.: 30P2974
EAN: 4044774730769
MPN:
4726032
H07Z-K 90°C 1X2,5 BN
Series: H07Z-K
LAPP
4726032 LAPP Insulated stranded wires
Image may differ
Unit Price (€ / mtr.)
1.3804 € *
Available: 0 mtr.
Leadtime: On Request **
Total Price:
1.38 € *
Price list
Quantity
Price per unit*
1 mtr.
1.3804 €
10 mtr.
1.2257 €
50 mtr.
1.1186 €
100 mtr.
1.0353 €
500 mtr.
0.9401 €
*incl. VAT plus shipping costs
**Subject to prior sale

Stranded wire, high flexible, 4726032, LAPP KABEL

Halogen-free core cable, harmonized. For the use in control cabinet, rated voltage 450/750 V.

Features

  • Low corrosiveness of the gases in case of fire
  • Low smoke development/smoke gas density in case of fire
  • Flame retardant

Applications

  • For wiring lights, devices, switchgear and distribution boards
  • For installation in pipes, on, in and under plaster as well as in closed installation ducts
  • In buildings with a high concentration of persons or material values
  • For use in dry rooms
Technical specifications
Core insulation material polymer
Outer diameter 4.3 mm
AWG cross-section AWG 14
Colour brown
Halogen free Yes
Conductor category CL.5 = fine stranded
Cable material copper, bright
Cable cross-section 2.5 mm²
Rated voltage 750 V
Rated voltage U0 450 V
Standard number HAR
Test voltage 2.5 kV
Temperature range (active) 5 °C to 90 °C
Temperature range (unmoved) -40 °C to 90 °C
Logistics
Country of origin IT
Customs tariff number 85444995
Original Packaging Ring with 100 meters
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
