4724073 | LAPP
Switching strand, halogen free, H07Z1-K, 4.0 mm², blue, outer Ø 4.8 mm, 4724073
Unit Price (€ / mtr.)
1.2733 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
1.27 € *
Price list
Quantity
Price per unit*
1 mtr.
1.2733 €
10 mtr.
1.0829 €
50 mtr.
0.9877 €
100 mtr.
0.8925 €
500 mtr.
0.8211 €
*incl. VAT plus shipping costs
Subject to prior sale
Switching strand, 4724073, LAPP
The 4724073 is a halogen-free, low smoke cable with cross-linked insulation and low emission of corrosive gases. For wiring of lamps, machine tools and splitter and especially for applications where low smoke density and low emission of corrosive gases are required at in case of fire.
Applications
- Wiring of lamps, devices, switchgear cabinets and distribution boxes
- Installation in tubes, on, in and under plaster as well as in closed installation ducts
- Use in dry rooms
- Expanded ambient temperatures
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Temperature range (active) | -5 °C to 70 °C | |
| Test voltage | 2.5 kV | |
| Colour | blue | |
| Halogen free | Yes | |
| Outer diameter | 4.8 mm | |
| Bending radius unmoved | 19.2 mm | |
| Conductor category | CL.5 = fine stranded | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Rated voltage U0 | 450 V | |
| Standard number | VDE | |
| Rated voltage | 750 V | |
| Product type | switching strand | |
| Cable material | copper, bright | |
| Cable cross-section | 4.0 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
| Country of origin | IT |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
