4527061 | LAPP
PVC-switching wire, H07V-U, 1.5 mm², gray, outer Ø 3.2 mm, 4527061
Unit Price (€ / mtr.)
0.4522 € *
Available: 0 mtr.
Leadtime: 1 Week **
Switching wire, 4527061, LAPP
The 4527061 is a single-conductor cables with thermoplastic PVC-insulation for installation inside of closed conduits and cable ducting systems and on or under plaster as well as in similar closed systems. It is suitable for protected, stationary use in or on lighting installation or control units/ switchgear in conjunction with voltages up to 1000 V AC or 750 V DC to-ground.
Features
- Flame-retardant
Applications
- Laying in tubes
- Direct laying on racks, troughs and tubes only as potential equalisation conductor
Technical specifications
| Rated voltage | 750 V | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Core insulation material | PVC | |
| Conductor category | CL.1 = stranded | |
| Standard number | VDE | |
| Halogen free | No | |
| Cable cross-section | 1.5 mm² | |
| Outer diameter | 3.2 mm | |
| Colour | gray | |
| Rated voltage U0 | 450 V | |
| Bending radius unmoved | 12.8 mm | |
| Cable material | copper, bright | |
| Test voltage | 2.5 kV |
Download
Logistics
| Country of origin | IT |
| Customs tariff number | 85444995 |
Compliance
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
