4527032 | LAPP
PVC-switching wire, H07V-U, 2.5 mm², brown, outer Ø 3.9 mm, 4527032
Unit Price (€ / mtr.)
0.7497 € *
Available: 100 mtr.
Switching wire, 4527032, LAPP
The 4527032 is a single-conductor cables with thermoplastic PVC-insulation for installation inside of closed conduits and cable ducting systems and on or under plaster as well as in similar closed systems. It is suitable for protected, stationary use in or on lighting installation or control units/ switchgear in conjunction with voltages up to 1000 V AC or 750 V DC to-ground.
Features
- Flame-retardant
Applications
- Laying in tubes
- Direct laying on racks, troughs and tubes only as potential equalisation conductor
Technical specifications
| Bending radius unmoved | 15.6 mm | |
| Test voltage | 2.5 kV | |
| Rated voltage U0 | 450 V | |
| Rated voltage | 750 V | |
| Cable material | copper, bright | |
| Cable cross-section | 2.5 mm² | |
| Standard number | VDE | |
| Halogen free | No | |
| Conductor category | CL.1 = stranded | |
| Core insulation material | PVC | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Outer diameter | 3.9 mm | |
| Colour | brown |
Download
Logistics
| Country of origin | IT |
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
