4527021 | LAPP
PVC-switching wire, H07V-U, 1.5 mm², blue, outer Ø 3.2 mm, 4527021
Unit Price (€ / mtr.)
0.4522 € *
Available: 200 mtr.
Switching wire, 4527021, LAPP
The 4527021 is a single-conductor cables with thermoplastic PVC-insulation for installation inside of closed conduits and cable ducting systems and on or under plaster as well as in similar closed systems. It is suitable for protected, stationary use in or on lighting installation or control units/ switchgear in conjunction with voltages up to 1000 V AC or 750 V DC to-ground.
Features
- Flame-retardant
Applications
- Laying in tubes
- Direct laying on racks, troughs and tubes only as potential equalisation conductor
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Bending radius unmoved | 12.8 mm | |
| Core insulation material | PVC | |
| Standard number | VDE | |
| Outer diameter | 3.2 mm | |
| Test voltage | 2.5 kV | |
| Cable material | copper, bright | |
| Conductor category | CL.1 = stranded | |
| Halogen free | No | |
| Colour | blue | |
| Rated voltage | 750 V | |
| Rated voltage U0 | 450 V | |
| Cable cross-section | 1.5 mm² | |
| Temperature range (unmoved) | -40 °C to 80 °C |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | IT |
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
