4527002 | LAPP
PVC-switching wire, H07V-U, 2.5 mm², green/yellow, outer Ø 3.9 mm, 4527002
Unit Price (€ / mtr.)
0.7616 € *
Standard delivery time from the manufacturer is: 1 Week
Switching wire, 4527002, LAPP
The 4527002 is a single-conductor cables with thermoplastic PVC-insulation for installation inside of closed conduits and cable ducting systems and on or under plaster as well as in similar closed systems. It is suitable for protected, stationary use in or on lighting installation or control units/ switchgear in conjunction with voltages up to 1000 V AC or 750 V DC to-ground.
Features
- Flame-retardant
Applications
- Laying in tubes
- Direct laying on racks, troughs and tubes only as potential equalisation conductor
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Cable material | copper, bright | |
| Conductor category | CL.1 = stranded | |
| Core insulation material | PVC | |
| Test voltage | 2.5 kV | |
| Cable cross-section | 2.5 mm² | |
| Bending radius unmoved | 15.6 mm | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Standard number | VDE | |
| Rated voltage U0 | 450 V | |
| Outer diameter | 3.9 mm | |
| Colour | green/yellow | |
| Rated voltage | 750 V | |
| Halogen free | No |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
| Country of origin | IT |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
