4512363S | LAPP
PVC-switching strand, X05V-K, 1.0 mm², purple/yellow, outer Ø 2.8 mm, 4512363S
Unit Price (€ / mtr.)
0.7021 € *
Standard delivery time from the manufacturer is: 6 Weeks
Single wire, 4512363S, LAPP
The 4512363S is a wiring cable with thermoplastic PVC-insulation for protected, stationary installation inside devices as well as inside or on lamps. Suitable for installation inside of closed conduits and cable ducting systems and on or under plaster, but only as part of signal or control circuits.
Features
- Twin-colour spiralized PVC
- Flame-retardant
Applications
- Internal wiring of devices
- Protected installation in and on lighting equipments
- Signal systems in and on plaster in tubes
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | PVC | |
| Cable material | copper, bright | |
| Conductor category | CL.5 = fine stranded | |
| Core insulation material | PVC | |
| Test voltage | 2 kV | |
| Cable cross-section | 1.0 mm² | |
| Bending radius unmoved | 11.2 mm | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Temperature range (active) | -5 °C to 70 °C | |
| Standard number | EN | |
| Rated voltage U0 | 300 V | |
| Outer diameter | 2.8 mm | |
| Colour | purple/yellow | |
| Rated voltage | 500 V | |
| Halogen free | No |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
