2170890/100 | LAPP
PVC ethernet cable, Cat 5, PROFINET, 4-wire, 0.5 mm², AWG 22, green, 2170890/100
Order No.: 30P1820
EAN: 4044776577379
MPN:
2170890/100
ETHERLINE PN Cat.5e FC
Series: ETHERLINE PN Cat.5e FRNC FLEX FC
Unit Price (€ / mtr.)
5.5454 € *
Standard delivery time from the manufacturer is: On Request
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Category | Cat 5 | |
| AWG cross-section | AWG 22 | |
| Core insulation material | PE | |
| Temperature range (active) | -40 °C to 80 °C | |
| Colour | green | |
| Halogen free | Yes | |
| Number of cores | 4 | |
| Shielding | shielded | |
| Outer diameter | 1.5 mm | |
| Temperature range (unmoved) | -25 °C to 80 °C | |
| Material | PVC | |
| Bussystem | PROFINET | |
| Version | ethernet cable | |
| Cable material | copper, bright | |
| Cable cross-section | 0.5 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444993 |
| Country of origin | QU |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
