1030461 | LAPP
PVC data cable, 16-wire, 0.14 mm², AWG 26, black, 1030461
Order No.: 33P7151
EAN: 4064727116983
MPN:
1030461
UNITRONIC LiYCY 16x0,14 BK
Series: UNITRONIC LiYCY BK
Unit Price (€ / mtr.)
2.8203 € *
Standard delivery time from the manufacturer is: 6 Weeks
Data cable, 1030461, LAPP
The 1030461 is a screened data cable for low frequency applications. The cable is designed for fixed installation and for conditional flexible use. It can be used in dry and damp rooms and also outdoors. The screen provides protection against electromagnetic interferences. The cable is used for example in computer systems, instrumentation technology, office equipment and balances.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 26 | |
| Colour | black | |
| Number of cores | 16 | |
| Outer diameter | 7 mm | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Shielding | shielded | |
| Temperature range (active) | -5 °C to 70 °C | |
| Cable material | copper, bright | |
| Halogen free | No | |
| Core insulation material | PVC | |
| Cable cross-section | 0.14 mm² | |
| Material | PVC | |
| Version | data cable |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
| Country of origin | QU |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
