1030459 | LAPP
PVC data cable, 14-wire, 0.14 mm², AWG 26, black, 1030459
Order No.: 33P7145
EAN: 4064727116907
MPN:
1030459
UNITRONIC LiYCY 14x0,14 BK
Series: UNITRONIC LiYCY BK
Unit Price (€ / mtr.)
2.4038 € *
Standard delivery time from the manufacturer is: 6 Weeks
Data cable, 1030459, LAPP
The 1030459 is a screened data cable for low frequency applications. The cable is designed for fixed installation and for conditional flexible use. It can be used in dry and damp rooms and also outdoors. The screen provides protection against electromagnetic interferences. The cable is used for example in computer systems, instrumentation technology, office equipment and balances.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | PVC | |
| Cable material | copper, bright | |
| Version | data cable | |
| Number of cores | 14 | |
| Shielding | shielded | |
| Core insulation material | PVC | |
| Cable cross-section | 0.14 mm² | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -5 °C to 70 °C | |
| Outer diameter | 6.7 mm | |
| Colour | black | |
| Halogen free | No | |
| AWG cross-section | AWG 26 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
| Country of origin | QU |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
