1030231 | LAPP
PVC data cable, 30-wire, 0.25 mm², AWG 24, black, 1030231
Order No.: 33P7279
EAN: 4064727113166
MPN:
1030231
UNITRONIC LiYY 30x0,25 BK
Series: UNITRONIC LiYY BK
Unit Price (€ / mtr.)
4.6648 € *
Standard delivery time from the manufacturer is: 6 Weeks
Data cable, 1030231, LAPP
The 1030231 is a data cable for low frequency applications. The cable is designed for fixed installation and for conditional flexible use. It can be used in dry and damp rooms and also outdoors. The cable is used for example in computer systems, instrumentation technology, office equipment and balances.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | PVC | |
| Cable material | copper, bright | |
| Version | data cable | |
| Number of cores | 30 | |
| Shielding | unshielded | |
| Core insulation material | PVC | |
| Cable cross-section | 0.25 mm² | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -5 °C to 70 °C | |
| Outer diameter | 10.3 mm | |
| Colour | black | |
| Halogen free | No | |
| AWG cross-section | AWG 24 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444993 |
| Country of origin | QU |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
