16001293 | LAPP
Rubber connection cable H07RN-F 5 G 2.5 mm², unshielded, black, 16001293
Unit Price (€ / mtr.)
4.3673 € *
Available: 15 mtr.
Total Price:
4.37 € *
Price list
Quantity
Price per unit*
1 mtr.
4.3673 €
10 mtr.
3.9746 €
50 mtr.
3.7604 €
100 mtr.
3.5105 €
500 mtr.
3.2725 €
*incl. VAT plus shipping costs
Subject to prior sale
Power and control cable, 16001293, LAPP
The 16001293 designed for use subject to high mechanical load conditions in dry or damp rooms, suitable for outdoor use. Continuous operational movements, restricted guidance, usage of these cables in moving cable carriers or on motor drum guidance or under a strain of more than 15 N/mm² conductor cross section are not allowed.
Features
- Cold-resistant
- Mechanical resistance
- Oil-resistant
- UV-resistant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Halogen free | No | |
| Colour | black | |
| Test voltage | 2.5 kV | |
| Cable cross-section | 2.5 mm² | |
| Outer diameter | 15.1 mm | |
| Version | connection line | |
| Rated voltage U0 | 450 V | |
| Material | rubber | |
| Temperature range (active) | -25 °C to 60 °C | |
| Number of cores | 5 | |
| Protective conductor available | Yes | |
| Rated voltage | 750 V | |
| Temperature range (unmoved) | -25 °C to 60 °C | |
| Shielding | unshielded | |
| Core insulation material | rubber | |
| Conductor category | CL.5 = fine stranded | |
| Drag chain suitable | No | |
| Cable material | copper, bright |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
| Country of origin | IT |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
