1600103 | LAPP
Rubber connection cable H07RN-F 3 G 1.5 mm², unshielded, black, 1600103
Unit Price (€ / mtr.)
1.8445 € *
Available: 146 mtr.
Total Price:
1.84 € *
Price list
Quantity
Price per unit*
1 mtr.
1.8445 €
10 mtr.
1.6779 €
50 mtr.
1.5708 €
100 mtr.
1.4756 €
500 mtr.
1.3685 €
*incl. VAT plus shipping costs
Subject to prior sale
Power and control cable, 1600103, LAPP
The 1600103 designed for use subject to high mechanical load conditions in dry or damp rooms, suitable for outdoor use. Continuous operational movements, restricted guidance, usage of these cables in moving cable carriers or on motor drum guidance or under a strain of more than 15 N/mm² conductor cross section are not allowed.
Features
- Cold-resistant
- Mechanical resistance
- Oil-resistant
- UV-resistant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Cable cross-section | 1.5 mm² | |
| Rated voltage U0 | 450 V | |
| Test voltage | 2.5 kV | |
| Shielding | unshielded | |
| Temperature range (unmoved) | -25 °C to 60 °C | |
| Conductor category | CL.5 = fine stranded | |
| Temperature range (active) | -25 °C to 60 °C | |
| Material | rubber | |
| Cable material | copper, bright | |
| Protective conductor available | Yes | |
| Core insulation material | rubber | |
| Drag chain suitable | No | |
| Number of cores | 3 | |
| Outer diameter | 10.7 mm | |
| Version | connection line | |
| Rated voltage | 750 V | |
| Halogen free | No | |
| Colour | black |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
| Country of origin | RO |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
