1600096 | LAPP
Rubber connection cable H07RN-F 1 x 1.5 mm², unshielded, black, 1600096
Unit Price (€ / mtr.)
0.6902 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
0.69 € *
Price list
Quantity
Price per unit*
1 mtr.
0.6902 €
10 mtr.
0.6307 €
50 mtr.
0.5712 €
100 mtr.
0.5355 €
500 mtr.
0.4998 €
*incl. VAT plus shipping costs
Subject to prior sale
Power and control cable, 1600096, LAPP
The 1600096 designed for use subject to high mechanical load conditions in dry or damp rooms, suitable for outdoor use. Continuous operational movements, restricted guidance, usage of these cables in moving cable carriers or on motor drum guidance or under a strain of more than 15 N/mm² conductor cross section are not allowed.
Features
- Cold-resistant
- Mechanical resistance
- Oil-resistant
- UV-resistant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of cores | 1 | |
| Halogen free | No | |
| Core insulation material | rubber | |
| Drag chain suitable | No | |
| Cable material | copper, bright | |
| Colour | black | |
| Product type | connection cable | |
| Conductor category | CL.5 = fine stranded | |
| Outer diameter | 6.5 mm | |
| Cable cross-section | 1.5 mm² | |
| Protective conductor available | No | |
| Test voltage | 2.5 kV | |
| Temperature range (active) | -25 °C to 60 °C | |
| Temperature range (unmoved) | -25 °C to 60 °C | |
| Rated voltage | 750 V | |
| Rated voltage U0 | 450 V | |
| Shielding | unshielded | |
| Material | rubber |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | IT |
| Customs tariff number | 85444991 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
