0023279 | LAPP

PUR control line 1 x 300 mm², shielded, black, 0023279

Order No.: 33P2130

EAN: 4044774864112

MPN:

0023279

ÖLFLEX PETRO C HFFR 1X300 BK

Series: ÖLFLEX PETRO C HFFR 0,6/1 kV

Image may differ

Key Specification:

Product type control line

Number of cores 1

Cable cross-section 300 mm²

Colour black

Download Datasheet Technical specifications

As a private customer, you can buy this item as soon as we have it back in stock.

Description

Control line, 0023279, LAPP

The 0023279 is a robust cable designed for offshore applications like instance on oil rigs for the cabling of pumping stations, compressors and generators of drilling units. The tinned copper braiding serves as screening against electrical interference. Depending on normative interpretation the braiding also can be used as so-called „Braid Armour“.

Features

Flame-retardant
Halogen-free
Cold-resistant
Mechanical resistance
Oil-resistant
Interference signals
UV-resistant

Applications

Onshore and offshore applications
Particularly in wet areas of machine tools and transfer lines
Chemical and petrochemical industry
For indoor and outdoor use

Technical specifications

Filter	Property	Value
	Product type	control line
	Number of cores	1
	Cable cross-section	300 mm²
	Colour	black
	Material	PUR
	Outer diameter	34.7 mm
	Shielding	shielded
	Halogen free	Yes
	Protective conductor available	No
	Cable material	copper, tin-plated
	Conductor category	CL.5 = fine stranded
	Core insulation material	polyolefine
	Drag chain suitable	No
	Standard number	UL
	Rated voltage	1 kV
	Rated voltage U0	600 V
	Rated voltage UL/CSA	1 kV
	Temperature range (unmoved)	-50 °C to 90 °C
	Temperature range (active)	-40 °C to 90 °C
	Test voltage	4 kV
