53111730 | LAPP
Cable gland, with bend protection, M25, 30 mm, Clamping range 9 to 17 mm, IP68, black, 53111730
Order No.: 32P2833
EAN: 4044773174533
MPN:
53111730
SKINTOP BS-M 25x1,5 RAL9005 BK
Series: SKINTOP BS-M
Unit Price (€ / pc.)
2.9869 € *
Available: 3 pcs.
Total Price:
2.99 € *
Price list
Quantity
Price per unit*
1 pcs.
2.9869 €
25 pcs.
2.6299 €
100 pcs.
2.4157 €
500 pcs.
2.2729 €
1000 pcs.
2.0706 €
*incl. VAT plus shipping costs
Subject to prior sale
Cable gland, 53111730, LAPP
SKINTOP® BS-M, plastic cable gland with bending and anti-kink protection, to protect flexible cables, for moving machine parts
BENEFITS
- Reliable bending and anti-kink protection
- Cable conservation
- Functional reliability
- To protect flexible cables
TECHNICAL DATA
- Protection rating: IP68
- Temperature range: -20 °C to 100 °C
- Material: Polyamide
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | black | |
| Degree of protection (IP) | IP68 | |
| max. clamping range | 17 mm | |
| Length | 125 mm | |
| Product type | cable gland | |
| Version | with bend protection | |
| min. operating temperature | -20 °C | |
| Material | PA | |
| spanner size | 30 mm | |
| max. operating temperature | 100 °C | |
| min. clamping range | 9 mm | |
| Thread size | M25 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CH |
| Customs tariff number | 39269097 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
