53111310 | LAPP
Cable gland, M16, 19 mm, Clamping range 3.5 to 7 mm, IP69, black, 53111310
Order No.: 32P3114
EAN: 4044773176582
MPN:
53111310
SKINTOP STR-M 16x1,5RAL9005
Series: SKINTOP STR-M
Unit Price (€ / pc.)
0.9044 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
0.90 € *
Price list
Quantity
Price per unit*
1 pcs.
0.9044 €
10 pcs.
0.8330 €
25 pcs.
0.7973 €
50 pcs.
0.7378 €
100 pcs.
0.6902 €
*incl. VAT plus shipping costs
Subject to prior sale
Technical specifications
| Filter | Property | Value |
|---|---|---|
| spanner size | 19 mm | |
| max. clamping range | 7 mm | |
| min. operating temperature | -20 °C | |
| max. operating temperature | 100 °C | |
| Degree of protection (IP) | IP69 | |
| Thread size | M16 | |
| Length | 34 mm | |
| Colour | black | |
| Material | PA | |
| Product type | cable gland | |
| min. clamping range | 3.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 39269097 |
| Country of origin | CH |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
