53105100 | LAPP
Cable gland, M12, 16 mm, Clamping range 4 to 6 mm, IP68, silver, 53105100
Order No.: 32P2757
EAN: 4044777092314
MPN:
53105100
SKINTOP HYGIENIC M12X1,5
Series: SKINTOP HYGIENIC
Unit Price (€ / pc.)
41.8404 € *
Available: 1 pcs.
Total Price:
41.84 € *
Price list
Quantity
Price per unit*
1 pcs.
41.8404 €
5 pcs.
39.3295 €
15 pcs.
37.8182 €
50 pcs.
36.1522 €
150 pcs.
34.6409 €
*incl. VAT plus shipping costs
Subject to prior sale
SKINTOP® HYGIENIC / SKINTOP® HYGIENIC-R, resistant stainless steel cable gland with smooth surfaces for use in the product zone. Optimal for hygiene-critical areas resistant, edge-free, robust and reliable, no gaps, cavities or external threads - therefore no risk of contamination of food machines, equipment or components. Material and shape offer easy and safe cleaning. The blue colouring of the sealing material makes it clearly distinguishable from foodstuffs. A complete component allows easy installation from the outside. Metric connecting thread according to DIN EN 60423, basis for technical specifications DIN IEC 62444.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | silver | |
| Thread size | M12 | |
| max. clamping range | 6 mm | |
| Degree of protection (IP) | IP68 | |
| Length | 38.4 mm | |
| max. operating temperature | 100 °C | |
| min. operating temperature | -20 °C | |
| spanner size | 16 mm | |
| Material | stainless steel | |
| Product type | cable gland | |
| min. clamping range | 4 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 73269098 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
