52106725 | LAPP
Cable gland, M20, 20/22 mm, Clamping range 8 to 12 mm, IP55, 52106725
Order No.: 32P2012
EAN: 4044773169997
MPN:
52106725
SKINDICHT SHZ-M-XL 20x1,5/11
Series: SKINDICHT SHZ
Unit Price (€ / pc.)
10.6148 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
10.61 € *
Price list
Quantity
Price per unit*
1 pcs.
10.6148 €
10 pcs.
9.6033 €
25 pcs.
9.0797 €
50 pcs.
8.5918 €
100 pcs.
8.0801 €
*incl. VAT plus shipping costs
Subject to prior sale
Technical specifications
| Filter | Property | Value |
|---|---|---|
| spanner size | 20/22 mm | |
| max. operating temperature | 80 °C | |
| max. clamping range | 12 mm | |
| Thread size | M20 | |
| Length | 39 mm | |
| Degree of protection (IP) | IP55 | |
| Material | brass, nickel-plated | |
| min. clamping range | 8 mm | |
| min. operating temperature | -20 °C | |
| Product type | cable gland |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 74198090 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
