52020513 | LAPP
Cable gland, M16, 15 mm, Clamping range 5 to 10 mm, IP54, light gray, 52020513
Unit Price (€ / pc.)
0.2451 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
0.25 € *
Price list
Quantity
Price per unit*
1 pcs.
0.2451 €
10 pcs.
0.2249 €
50 pcs.
0.2106 €
100 pcs.
0.1975 €
500 pcs.
0.1833 €
*incl. VAT plus shipping costs
Subject to prior sale
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | PE | |
| Thread size | M16 | |
| max. operating temperature | 80 °C | |
| max. clamping range | 10 mm | |
| Length | 17 mm | |
| Product type | cable gland | |
| min. clamping range | 5 mm | |
| min. operating temperature | -30 °C | |
| spanner size | 15 mm | |
| Degree of protection (IP) | IP54 | |
| Colour | light gray |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 39269097 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
