ZDFL 21X120B 10% 2K2 | KRAH
Wirewound resistor, 2.2 kΩ, 65 W, ±10 %, ZDFL 21X120B 10% 2K2
Unit Price (€ / pc.)
16.9813 € *
Available: 45 pcs.
Total Price:
16.98 € *
Price list
Quantity
Price per unit*
1 pcs.
16.9813 €
10 pcs.
14.9345 €
50 pcs.
13.9349 €
200 pcs.
13.1138 €
400 pcs.
12.5902 €
*incl. VAT plus shipping costs
Subject to prior sale
Cemented wire-wound power resistors, 65 W, tolerance 10 %, type KRAH ZDFL.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| diameter | 21 mm | |
| Power | 65 W | |
| max. operating temperature | 350 °C | |
| Tolerance | ±10 % | |
| Length | 120 mm | |
| Assembly | chassis mounting | |
| Design | chassis | |
| ohmic resistance | 2.2 kΩ | |
| Version | high load wire resistor |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Original Packaging | Bulk with 50 pieces |
| Customs tariff number | 85332900 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
