03.326.006.1 | Knürr
Outlet strip, 6-way, 2.5 m, 16 A, gray, 03.326.006.1
Schuko-style outlet strips, type Knürr Di-Strip Protector Not-Aus.
With double-pole emergency off switch (red) for personal protection. Safe isolation between phase and neutral conductor. The tripped switch must be released explicitly for restart. The unit can be mounted in 19-inch racks; Outlet angle: 45°. Outlet pitch: 50 mm. Dimensions: H 101 mm. Housing width: 44.4 mm (1 HU). Rating: 100 to 240 VAC/16 A. Design: CE label according to low voltage directive 73/23/EC and EMC directive 89/336/EC, DIN 49440. Housing: closed, galvanized steel sheet profile, powder-coated structure. Plastic components: Vampamide 6 0024 VO (UL 94 V-0). Internal conductor: continuous busbars made of brass. Patch cord: H05VV-F3G 1.5 mm², 2.5 m, PVC, with molded angled plug. Color: light-gray. Red impact pushbutton actuator.
Compact version with 50 mm outlet pitch, type 03.326.
Technical attributes (type, number of outlets, color, dimension L): 03.326.006.1, 6 outlets, RAL 7035 light-gray, L 483 mm
| Cable length | 2.5 m | |
| USB connection | No | |
| Depth | 101 mm | |
| Overvoltage protection | No | |
| Length | 483 mm | |
| Master-Slave | No | |
| Number of sockets | 6 | |
| Colour | gray | |
| Material | sheet steel | |
| Rated current | 16 A | |
| Width | 44.4 mm | |
| Degree of protection (IP) | IP20 | |
| Can be switched off | Yes |
| Customs tariff number | 85366990 |
| Country of origin | HU |
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
