74 06 160 | Knipex
VDE power side cutter, 160 mm, 215 g, cut capacity (–/3.4/2.5/2 mm), 74 06 160
Order No.: 05L2592
EAN: 4003773040705
MPN:
74 06 160
7406160
Unit Price (€ / pc.)
39.1153 € *
Available: 1 pcs.
Available in 7 Days: 10 pcs. - if ordered today
Total Price:
39.12 € *
Price list
Quantity
Price per unit*
1 pcs.
39.1153 €
6 pcs.
35.2002 €
*incl. VAT plus shipping costs
Subject to prior sale
High leverage diagonal cutter, 74 06 160, Knipex
With integrated forged axle for heaviest duty. Suitable for all types of wire including piano wire. High cutting performance with minimum effort due to optimum co-ordination of the cutting edge angle and transmission ratio. Precision cutting edges additionally induction-hardened, cutting edge hardness approx. 64 HRC. Chrome vanadium heavy-duty steel, forged, multi stage oil-hardened
Technical Data
- Material: Chromium-Vanadium steel
- Weight: 215 g
- Length: 160 mm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | chromium-vanadium steel | |
| Cutting capicity (Piano wire) | 2 mm | |
| ESD protection | No | |
| Length | 160 mm | |
| 1000V Insulated | Yes | |
| Cutting edge | with facet | |
| Weight | 215 g | |
| Cutting capacity (medium-hard) | 3.4 mm | |
| Cutting capicity (hard) | 2.5 mm | |
| Version | power side cutter |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 82032000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | not_relevant |
| SVHC free | Yes |
