485/21 | Kleinhuis
Locking screw, PG21, Clamping range 10 to 18 mm, IP54, light gray, 485/21
Order No.: 06N393
EAN: 4099891198053
MPN:
485/21
Unit Price (€ / pc.)
0.8092 € *
Standard delivery time from the manufacturer is: On Request
Screw-on nipple PG 21 for cable junction boxes, type 485/21
Sealing nipple with opening, elastic polyethylene.
Color: gray
Sealing range from/to: 10 / 18
Thread length: 11 mm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| max. operating temperature | 80 °C | |
| max. clamping range | 18 mm | |
| Thread size | PG21 | |
| Length | 33 mm | |
| Colour | light gray | |
| Degree of protection (IP) | IP54 | |
| Material | PE | |
| min. clamping range | 10 mm | |
| min. operating temperature | -40 °C | |
| Product type | locking screw |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 39269097 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
