CL900 | Klein Tools

TRMS AC/DC current clamp CL900, 2000 A (DC), 2000 A (AC), 1000 V (DC), 1000 V (AC), opening 51 mm, CAT III 1000 V, CAT IV 600 V

Order No.: 25L0130
EAN: 092644692352
MPN:
CL900
Klein Tools
CL900 Klein Tools Clamp Meters Image 1
CL900 Klein Tools Clamp Meters Image 2
CL900 Klein Tools Clamp Meters Image 3
Image may differ
Print
Key Specification:
Product type AC/DC current clamp
Version IP40
TRMS possible Yes
Pliers opening 51 mm
Surge voltage category CAT III 1000 V, CAT IV 600 V
Download Datasheet Technical specifications

NCNR (non cancelable / non returnable)

Unit Price (€ / pc.)
214.0810 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
214.08 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
214.0810 €
Description
Technical specifications
Download
Logistics
Compliance

Clamp Meters, CL900, Klein Tools

The CL900 Electrical Tester is an auto-ranging, true root mean square (TRMS) digital clamp meter. It measures AC/DC current via the clamp and measures AC/DC voltage, resistance, continuity, frequency, duty-cycle, capacitance, and tests diodes via test-leads. It features a Low Impedance (LoZ) mode for identifying and eliminating ghost or stray voltages, and has a dedicated mode for capturing Inrush Current.

Features

  • Rugged Klein TOUGH METER industrial design stands up to jobsite demands; built to withstand a 6.6-Foot (2m) drop
  • Automatically ranging True Root Mean Squared (TRMS) measurement technology for accuracy
  • Backlit display for clear visibility in environments with low ambient lighting
  • Dedicated mode for capturing Inrush Current
  • Non-contact voltage tester integrated into the clamp
  • Low impedance (LoZ) mode for identifying and eliminating ghost or stray voltages
  • Audible continuity, capacitance, diode test, frequency and duty cycle, min/max feature, data hold capability
  • Test leads measure AC/DC voltage, resistance, continuity, frequency, duty-cycle, capacitance and diodes
Technical specifications
Product type AC/DC current clamp
Version IP40
TRMS possible Yes
Pliers opening 51 mm
Surge voltage category CAT III 1000 V, CAT IV 600 V
max. measured current value (DC) 2000 A
max. measured current value (AC) 2000 A
max. voltage measuring range (DC) 1000 V
max. voltage measuring range (AC) 1000 V
max. resistance range 60 MΩ
min. Measured value (frequency) 10 Hz
max. measured value (frequency) 500 kHz
Articles of same specification 0
Logistics
Country of origin CN
Customs tariff number 90303100
Compliance
SVHC free Yes
Electrical equipment take-back Electrical equipment take-back
RoHS conform Yes
Date of RoHS guidelines 3/31/15
