43612 | Klauke
Insulated wire end ferrule, 10 mm², 24 mm/12 mm long, red, 43612
Order No.: 18H7502
EAN: 4012078038706
MPN:
43612
Unit Price (€ / pc.)
0.7616 € *
Available: 100 pcs.
Total Price:
0.76 € *
Price list
Quantity
Price per unit*
1 pcs.
0.7616 €
10 pcs.
0.6902 €
50 pcs.
0.6188 €
100 pcs.
0.5474 €
500 pcs.
0.4879 €
*incl. VAT plus shipping costs
Subject to prior sale
Wire end ferrule, 43612, KLAUKE
Insulated wire-end ferrule for short circuit protected conductors for fine and superfine stranded conductors, according to DIN EN 60228 Cl. 5 and 6, for short-circuit-proof lines (according NSGAFÖU). Contains Easy-Entry insulation for easy cable entry.
Features
- Halogen free
- Tin plated to protect against corrosion
- Color-coded cross-section assignment
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | red | |
| Cable cross-section | 10 mm² | |
| Isolated | Yes | |
| max. operating temperature | 105 °C | |
| Contact material | copper | |
| Material Insulation | polypropylene | |
| Length | 24 mm | |
| Pin lenght | 12 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
