17218 | Klauke
Insulated wire end ferrule, 1.5 mm², 24 mm/18 mm long, DIN 46228-4, black, 17218
Order No.: 18H7405
EAN: 4012078023481
MPN:
17218
Unit Price (€ / pc.)
0.1285 € *
Available: 60 pcs.
Total Price:
1.29 € *
Price list
Quantity
Price per unit*
10 pcs.
0.1285 €
100 pcs.
0.1142 €
500 pcs.
0.1012 €
1000 pcs.
0.0893 €
5000 pcs.
0.0738 €
*incl. VAT plus shipping costs
Subject to prior sale
Wire end ferrule, 17218, KLAUKE
Insulated wire-end ferrule to DIN with Easy-Entry insulation for splice-free cable entry, colour code 2, for fine and superfine stranded conductors, according to DIN EN 60228 Cl. 5 and 6.
Features
- Halogen free
- Tin plated to protect against corrosion
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Cable cross-section | 1.5 mm² | |
| Isolated | Yes | |
| Colour | black | |
| Length | 24 mm | |
| Pin lenght | 18 mm | |
| Standard number | DIN 46228-4 | |
| Contact material | copper | |
| Material Insulation | polypropylene | |
| max. operating temperature | 105 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85369010 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
