920V | Klauke
Insulated round plug sleeve, 4 mm, 0.5 to 1.0 mm², AWG 20 to 18, bronze, tin-plated, red, 920V
Order No.: 05F601
EAN: 4012078489157
MPN:
920V
Unit Price (€ / pc.)
0.7259 € *
Available: 104 pcs.
Total Price:
0.73 € *
Price list
Quantity
Price per unit*
1 pcs.
0.7259 €
10 pcs.
0.6783 €
25 pcs.
0.6307 €
50 pcs.
0.5712 €
*incl. VAT plus shipping costs
Subject to prior sale
Insulated receptacle, 920V, Klauke
Fully insulated round plug sleeve for 4 mm plugs, 24 mm long, Nominal cross section: 0.5 to 1.0 mm², Colour: red, Material: bronze (CuSnZn), Tin-plated, Insulating sleeve: PA (halogen-free), Temperature resistance: up to 105 °C.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | round plug sleeve | |
| Suitable for | 4 mm | |
| Material | bronze, tin-plated | |
| Isolated | Yes | |
| Insulation colour | red | |
| Connection | crimp connection | |
| Cable cross-section | 0.5 to 1.0 mm² | |
| AWG cross-section | AWG 20 to 18 | |
| Length | 24 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
