120B | Klauke
Butt connector, uninsulated, 120 mm², metal, 50 mm, 120B
Order No.: 07F1333
EAN: 4012078800730
MPN:
120B
Unit Price (€ / pc.)
3.8913 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
3.89 € *
Price list
Quantity
Price per unit*
1 pcs.
3.8913 €
10 pcs.
3.4986 €
50 pcs.
3.1535 €
100 pcs.
2.8441 €
*incl. VAT plus shipping costs
Subject to prior sale
Butt connector, 120B, Klauke
Butt connector for compacted, multi-stranded round conductors.
Features
- Accurate assignment of crimping tool/crimping die through colour-coding system
- Less crimpings due to max. crimping width
- Reduced costs due to compact dimensions
- Processing without use of additional sleeves
- Annealed material optimises material and crimping properties
- Reliable tool selection by matching code indication on the butt connector
- Simple cable entry due to precise internal chamfer
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Length | 50 mm | |
| Colour | metal | |
| Material | copper, tin-plated | |
| Isolated | No | |
| shrinkable tubing | No | |
| Version | butt connector | |
| Cable cross-section | 120 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85369010 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
